"LI" make Autoclaves are designed and fabricated for steam sterilization process to Kill micro-organism through the application of saturated steam under pressure to suit various I.S. standards application in the growing field of Medical, Agricultural Institution, Bio-Chemical Industrial, Research laboratories and Various Industries.
Autoclave Steam Sterlizer
Specification
Application: For use in Microbiology, QC & Research laboratory - Pharma industry
•Double wall design has single chamber for steam and water
•Fully automatic operation; cycle begins by press of the START button
•Initial air purging cycle; at the start air is automatically removed from the chamber
•Microprocessor based digital temperature indicator controller controls temperature / pressure precisely at set value
•Temperature sensor: PT – 100
•In built digital timer; timer can be adjusted as per sterilization load requirement
•Automatic steam exhaust at the end of cycle
•Low water level heater safeguard.
•Safety high pressure release valve
•Safety high temperature cut off. Included if ordered separately
•Working chamber made of stainless steel LM 304 grade of 2mm thickness
•Outer cover made of stainless steel 1mm thick
•Lid, flange & bottom sheet also made of stainless steel. All joints argon welded
•Joint less silicon gasket. Heavy duty industrial flange heater
•Pressure range: 15 to 22 PSI, factory set at 15 PSI
•Temperature range: 121°C to 125°C
•Temperature resolution: 0.1°C / temperature accuracy: ±0.5°C
•Lid fitting pressure gauge 0-30 PSI, safety spring loaded pressure valve, steam release valve
•Hydraulically tested at 60PSI
•Foot lifting arrangement included for size 18”x 24”, 18” x 30” & 22” x 30”
•Electrical: 230V / 15A / 50 Hz
Application: For use in Microbiology, QC & Research laboratory - Pharma industry
•Double wall design has single chamber for steam and water
•Fully automatic operation; cycle begins by press of the START button
•Initial air purging cycle; at the start air is automatically removed from the chamber
•Microprocessor based digital temperature indicator controller controls temperature / pressure precisely at set value
•Temperature sensor: PT – 100
•In built digital timer; timer can be adjusted as per sterilization load requirement
•Automatic steam exhaust at the end of cycle
•Low water level heater safeguard.
•Safety high pressure release valve
•Safety high temperature cut off. Included if ordered separately
•Working chamber made of stainless steel LM 304 grade of 2mm thickness
•Outer cover made of stainless steel 1mm thick
•Lid, flange & bottom sheet also made of stainless steel. All joints argon welded
•Joint less silicon gasket. Heavy duty industrial flange heater
•Pressure range: 15 to 22 PSI, factory set at 15 PSI
•Temperature range: 121°C to 125°C
•Temperature resolution: 0.1°C / temperature accuracy: ±0.5°C
•Lid fitting pressure gauge 0-30 PSI, safety spring loaded pressure valve, steam release valve
•Hydraulically tested at 60PSI
•Foot lifting arrangement included for size 18”x 24”, 18” x 30” & 22” x 30”
•Electrical: 230V / 15A / 50 Hz
