Specification
•Temperature range: +2.0°C to +8.0°C. Accuracy / Uniformity: ±5°C/±1.0°C.
•Temperature display: Digital LED 3˝ digit
•Control: Microprocessor based PID control. With Auto tune CE marked
•Resolution: ±0.1°C
•Temperature sensor: PT – 100
•Heating: ‘U’ shaped Nichrome wire heater in SS sheathing
•Cooling: CFC free Kirloskar make compressor utilizing R 134A eco friendly
refrigerant, with condenser, motor and relay
•Air circulation: Flange motor with impeller / blower
•Construction: Double wall, with insulation, outer door key lockable, inner
glass viewing door
•Chamber illumination: Fluorescent light with door switch
•Safety Features
: High temperature safety cut off
: Electrical overload cutoff relay for compressor
: Time delay for compressor switch ON
: Electrical circuit breaker
•Feet : Castor wheels
•Trays : SS wire mesh heavy duty
•Electrical: 230V / 15A / 50 Hz.
•Temperature range: +2.0°C to +8.0°C. Accuracy / Uniformity: ±5°C/±1.0°C.
•Temperature display: Digital LED 3˝ digit
•Control: Microprocessor based PID control. With Auto tune CE marked
•Resolution: ±0.1°C
•Temperature sensor: PT – 100
•Heating: ‘U’ shaped Nichrome wire heater in SS sheathing
•Cooling: CFC free Kirloskar make compressor utilizing R 134A eco friendly
refrigerant, with condenser, motor and relay
•Air circulation: Flange motor with impeller / blower
•Construction: Double wall, with insulation, outer door key lockable, inner
glass viewing door
•Chamber illumination: Fluorescent light with door switch
•Safety Features
: High temperature safety cut off
: Electrical overload cutoff relay for compressor
: Time delay for compressor switch ON
: Electrical circuit breaker
•Feet : Castor wheels
•Trays : SS wire mesh heavy duty
•Electrical: 230V / 15A / 50 Hz.
STD Model GMP Model
• Outer cabinet mild steel powder coated •Outer cabinet SS 304 grade dull matt finish
•Inner chamber stainless steel 304 grade •Inner chamber stainless steel mirror finish
Pre Installation Mandatory Requirement :
(Guarantee void incase of non compliance)
a) Room temperature around machine preferably at 25°C with air conditioner or a well ventilated room
with exhaust fan. However surrounding temperature should not exceed 30°C.
b) Stabilized input voltage of 230V AC 20 Amps. Use of servo controlled stabilizer is recommended.
(Guarantee void incase of non compliance)
a) Room temperature around machine preferably at 25°C with air conditioner or a well ventilated room
with exhaust fan. However surrounding temperature should not exceed 30°C.
b) Stabilized input voltage of 230V AC 20 Amps. Use of servo controlled stabilizer is recommended.
Cooling Incubator
